The desflow command runs a model without a line of Python, and also checks it, compares designs, fits measured times and converts a distribution's parameters. This page uses each command in the order a study uses it, on one shop, and says what each output tells you.

What It Is

desflow is installed with the package: uv tool install desflow, or pip install desflow. Each task is a command of its own, such as desflow run or desflow explain. desflow on its own lists them by task, with examples. The --help of each command, such as desflow run --help, lists its options and ends with examples of that command. CLI gives the help of every command, with every option.

The shop on this page is the model of the experiment example: two packers, an order every 2.5 seconds on average, and 4 seconds of packing on average. Every command runs in one folder and needs no Docker service. desflow fit needs the fit extra: uv tool install "desflow[fit]", or pip install "desflow[fit]".

How to Use It

Get an Example

desflow --version prints the release you installed. desflow examples list, or desflow examples alone, lists every example with the service it needs, such as (no service) or (odctl up kafka-lite):

1
2
3
desflow --version
desflow examples list
desflow examples

desflow examples get downloads one example at the release you installed, into a folder named after it:

1
desflow examples get experiment --api yaml

1
2
3
4
5
6
wrote experiment/yaml/experiment.yaml
wrote experiment/yaml/experiment_shop.yaml
wrote experiment/observed_waits.csv

Find the bottleneck, with no run: cd experiment/yaml && desflow explain experiment_shop.yaml
Run the yaml version: cd experiment/yaml && desflow experiment experiment.yaml

The model is experiment_shop.yaml, and experiment.yaml is the experiment that compares two designs of it. observed_waits.csv holds the mean wait measured in the real shop. The line before the last runs desflow explain on the model, and the last line is the command that runs the example from its own folder. --api builder or --api low-level downloads the same example in Python.

--dest downloads into another folder, and --ref downloads from another tag or branch, such as main for an example added after your release:

1
desflow examples get experiment --api builder --dest shop --ref main

1
2
3
4
wrote shop/experiment/builder/experiment_example.py
wrote shop/experiment/observed_waits.csv

Run the builder version: cd shop/experiment/builder && python experiment_example.py

The builder version goes under shop/experiment/builder, and the last line runs it from there. A file that is already there stops the download before anything is written, and --force replaces it instead. This line downloads the YAML version again, over the files of the first download, and prints the same lines as the first download:

1
desflow examples get experiment --api yaml --force

Check It Before a Long Run

desflow explain reads the model without running it. It draws the model as a graph and works out each resource's utilisation, the share of its units that the arrivals keep busy:

1
desflow explain experiment/yaml/experiment_shop.yaml

desflow explain on the experiment's shop: the graph of orders, pack and packers, the resources table with utilisation 0.8, the table of 1 to 4 packers and the hints

The same output as text:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Shop
`-- orders (arrival, rate 0.4/s)
    `-- spawn -> pack (task, rate 0.4/s)
        +-- uses packers (resource)
        `-- next (share 1) -> exit
Resources
+---------------------------------------------------+
| resource |   λ |    μ | c |   ρ | Wq | L | status |
|----------+-----+------+---+-----+----+---+--------|
| packers  | 0.4 | 0.25 | 2 | 0.8 |  - | - | OK     |
+---------------------------------------------------+
packers by units
+-----------------------+
| c |      ρ | status   |
|---+--------+----------|
| 1 |    1.6 | UNSTABLE |
| 2 |    0.8 | OK       |
| 3 | 0.5333 | OK       |
| 4 |    0.4 | OK       |
+-----------------------+
Bottleneck: packers
Not estimated:
  wait at packers: no closed formula for c > 1 with non-exponential times; run --verify to measure it
Hints for utilisation 0.85:
  packers with 2 units: utilisation 0.8, at most 0.85
  packers with 2 units: utilisation 0.85 at a request every 2.35 seconds (25.5 a minute, 0.425 a second)

The packers are at utilisation 0.8. An order arrives every 2.5 seconds on average (24 a minute, rate 0.4/s in the graph, λ in the table). Each order needs 4 seconds of a packer, and 2 packers share the work. μ is the rate one packer serves, 0.25 orders a second (4 seconds each), and ρ is the utilisation. Wq is the mean wait in the queue and L the mean number of orders in the shop, shown as - when no formula applies. The status is OK below 0.85, CONGESTED from 0.85 and UNSTABLE from 1, where the queue grows for as long as the run lasts. The table by units shows that one packer would be UNSTABLE. The hints give the units and the arrival rate that reach the target of 0.85. A hint of more units than the resource's max_cap also says to raise max_cap, because a current_cap above max_cap is clamped to it. The formulas give no wait for two packers with gamma packing times, so the line under Not estimated says to measure it. Queues and Capacity works the same numbers out by hand.

--verify measures it. It runs the model unpaced and compares each statistic with the analysis, as Check Against Theory shows. With --replications, it runs the model that many times from --seed, each to --until, and compares with each measure's 95% interval. --target sets the utilisation the hints aim for:

1
2
# Ten one-hour runs compared with the analysis, and hints for utilisation 0.9
desflow explain experiment/yaml/experiment_shop.yaml --verify --replications 10 --seed 42 --until 1h --target 0.9

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
Shop
`-- orders (arrival, rate 0.4/s)
    `-- spawn -> pack (task, rate 0.4/s)
        +-- uses packers (resource)
        `-- next (share 1) -> exit
Resources
+---------------------------------------------------+
| resource |   λ |    μ | c |   ρ | Wq | L | status |
|----------+-----+------+---+-----+----+---+--------|
| packers  | 0.4 | 0.25 | 2 | 0.8 |  - | - | OK     |
+---------------------------------------------------+
packers by units
+-----------------------+
| c |      ρ | status   |
|---+--------+----------|
| 1 |    1.6 | UNSTABLE |
| 2 |    0.8 | OK       |
| 3 | 0.5333 | OK       |
| 4 |    0.4 | OK       |
+-----------------------+
Bottleneck: packers
Not estimated:
  wait at packers: no closed formula for c > 1 with non-exponential times
Hints for utilisation 0.9:
  packers with 2 units: utilisation 0.8, at most 0.9
  packers with 2 units: utilisation 0.9 at a request every 2.22 seconds (27 a minute, 0.45 a second)
Verify: 10 runs to 3600 s, seed 42
+------------------------------------------------------------------------+
| node    | measure      | analysis | measured |        ± | result       |
|---------+--------------+----------+----------+----------+--------------|
| packers | utilization  |      0.8 |   0.7953 |  0.01561 | agrees       |
| packers | queue_length |        - |    1.823 |   0.2856 | not compared |
| pack    | wait         |        - |    4.505 |   0.6483 | not compared |
| orders  | throughput   |      0.4 |   0.4002 | 0.007201 | agrees       |
+------------------------------------------------------------------------+
Not compared:
  packers queue_length: no closed formula for c > 1 with non-exponential times
  pack wait: no closed formula for c > 1 with non-exponential times
--verify checks the implementation against the queueing analysis where it applies; it does not show that the model is close enough to the real system

The measured utilisation of 0.7953 and throughput of 0.4002 agree with the analysis, so the model does what the formulas say. The wait has no formula here, so the runs only measure it: 4.505 seconds. With a target of 0.9, the hints say that two packers reach it at an order every 2.22 seconds. --json prints the same explanation as one JSON object, for a script to read. Its schema_version names the shape, which the Explanation class describes:

1
desflow explain experiment/yaml/experiment_shop.yaml --json > explain.json

Run It

desflow run --sample prints the first events as JSON lines. It runs the model unpaced, with no ingress, and with no sinks of the file's own, so a model that writes to Kafka or a database needs no service:

1
desflow run experiment/yaml/experiment_shop.yaml --sample 5

1
2
3
4
5
{"stream_type":"event","sim_ts":3.19,"timestamp":"...","key":"orders-1","task":"pack","instance":0,"value":{"path_id":"Shop.service.packing","status":"queued"}}
{"stream_type":"event","sim_ts":3.19,"timestamp":"...","key":"orders-1","task":"pack","instance":0,"value":{"path_id":"Shop.service.packing","status":"started"}}
{"stream_type":"event","sim_ts":3.37,"timestamp":"...","key":"orders-2","task":"pack","instance":1,"value":{"path_id":"Shop.service.packing","status":"queued"}}
{"stream_type":"event","sim_ts":3.37,"timestamp":"...","key":"orders-2","task":"pack","instance":1,"value":{"path_id":"Shop.service.packing","status":"started"}}
{"stream_type":"event","sim_ts":4.672,"timestamp":"...","key":"orders-3","task":"pack","instance":2,"value":{"path_id":"Shop.service.packing","status":"queued"}}

Each order publishes queued when it joins the packers' queue and started when a packer takes it. The first two orders find a packer free, so each starts at the moment it queues. Without --sample, desflow run runs the model with its own settings and sinks.

One run is one sample, so measure the wait with replications: the same model with ten seeds, each run for one hour:

1
desflow run experiment/yaml/experiment_shop.yaml --replications 10 --seed 42 --until 1h

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
measure                                n          mean    half-width (95%)
resources.packers.capacity            10             2                   0
resources.packers.in_use              10           1.8              0.3016
resources.packers.queue_length        10             4               3.422
resources.packers.utilization         10            90               15.08
resources.packers.utilization_avg     10         79.53               1.561
resources.packers.queue_length_avg    10         1.823              0.2856
tasks.pack.in_progress                10           5.8               3.566
tasks.pack.finished                   10          1441               25.92
tasks.pack.wait_mean                  10         4.505              0.6483
tasks.pack.wait_max                   10         28.84               4.347
tasks.pack.service_mean               10         3.972             0.04102
tasks.pack.service_max                10         14.64              0.8328
flows.orders.finished                 10          1441               25.92
flows.orders.started                  10          1446               26.78
flows.orders.in_system                10           5.8               3.566

Seed 42; replication seeds: 2684470948, 4091952314, 233227757, 3276785861, 3644269654, 1206282609, 3543069911, 3479688010, 877132087, 1244265337
Repeat one replication with: desflow run experiment/yaml/experiment_shop.yaml --seed <its seed> --until 1h

The mean wait is 4.505 seconds, and its half-width of 0.6483 says that the true mean lies within about 0.65 seconds of it, with 95% confidence. The packers are busy 79.53% of the time, close to the 0.8 that explain worked out. The last line repeats any one replication, with its events. This shop has no sinks. A model with a sink, such as type: Console, also sends the result to it as telemetry: one reading for each replication and measure. A Console sink therefore prints those lines before the table, as What the Sinks Receive explains.

--measure names a statistic to summarise, and repeats for more. --level sets the confidence level of the intervals. --workers runs that many replications at once, each in its own process, and gives the same results, because each replication keeps its seed:

1
2
# Two statistics at a 99% level, two replications at a time
desflow run experiment/yaml/experiment_shop.yaml --replications 10 --seed 42 --until 1h --measure tasks.pack.wait_mean --measure resources.packers.utilization_avg --level 0.99 --workers 2

1
2
3
4
5
6
measure                               n          mean    half-width (99%)
tasks.pack.wait_mean                 10         4.505              0.9314
resources.packers.utilization_avg    10         79.53               2.243

Seed 42; replication seeds: 2684470948, 4091952314, 233227757, 3276785861, 3644269654, 1206282609, 3543069911, 3479688010, 877132087, 1244265337
Repeat one replication with: desflow run experiment/yaml/experiment_shop.yaml --seed <its seed> --until 1h

The means are the same as before. At 99%, the half-width of the mean wait grows from 0.6483 to 0.9314 seconds, because more confidence needs a wider interval.

--stdout prints the run's records as JSON lines, instead of writing to the file's sinks. --drain stops the arrivals at the end time and runs on until every order has left. This run stops the arrivals at 20 seconds, and its last record is the ninth order packed, at 24.789 seconds:

1
2
# Every record of a 20-second run that drains, as JSON lines in a file
desflow run experiment/yaml/experiment_shop.yaml --seed 42 --until 20 --drain --stdout > records.jsonl

Compare Designs

desflow experiment runs an experiment: here two packers against three, 20 replications of each with the same seeds, with a check that three packers keep the mean wait under 2 seconds. --output names the folder for its files, here results/packers in the current folder. Without it, they go to the folder the file's output names, beside the file:

1
desflow experiment experiment/yaml/experiment.yaml --output results/packers

1
2
Wrote the artifacts and report.md to results/packers
passed: three: tasks.pack.wait_mean max 2, checked 0.5919

The check passed: the upper end of the interval of the mean wait with three packers is 0.5919 seconds, under the bound of 2. The command exits with status 1 when a check fails, so a CI job that runs it fails too. The six files in results/packers hold every value, and report.md compares the designs, as Experiment Results describes. After editing experiment.json by hand, desflow report builds the report again from the files, without running anything:

1
desflow report results/packers

1
Wrote results/packers/report.md

Fit Measured Times

A packing time in a model comes from measured times. The fitting example holds 40 packing times measured at a bench, for a shop of its own, and desflow fit fits every distribution family to them:

1
2
desflow examples get fitting --api yaml
desflow fit fitting/packing_times.csv --column packing_seconds --lower 0

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
40 rows: 40 used, 0 missing, 0 invalid
family            status              AIC  KS stat KS p (approx.)  parameters or reason
exponential       rejected                                         its std is 1.5, the data's is 0.4832: more than 25% apart
normal            fitted            59.33    0.157         0.2504  mean=1.5, std=0.483218 (can draw below the lower bound 0)
lognormal         fitted            57.33  0.09406         0.8385  mean=1.50251, std=0.511854
truncated_normal  fitted            59.25   0.1558         0.2579  mean=1.49836, std=0.48579, low=0
constant          skipped                                          the values are not all equal
uniform           fitted            59.45    0.225        0.02923  low=0.7, high=2.7
triangular *      fitted            56.68   0.1258          0.511  low=0.546332, mode=1.2, high=2.83766
gamma             fitted            56.79   0.1157         0.6165  shape=9.55777, scale=0.15694
weibull           fitted            58.99   0.1502         0.2972  shape=3.33522, scale=1.67203
empirical         fitted                                           values: 40 numbers
* best: triangular

The first line counts the values. Each row is one family: fitted with its AIC, where lower is better, or the reason it was not fitted. The triangular has the lowest AIC, 56.68, and the gamma is within 0.11 of it, so the data cannot tell the two apart. Fitting the Inputs checks what the choice changes.

The other options shape the fit, as Input Fitting describes:

  • --unit names the data's unit, ms, s, min or h, and the settings are written in seconds.
  • --upper is the highest plausible value, and a family that can draw above it is marked.
  • --candidates names the families to try.
  • --bins offers the empirical distribution as a histogram with that many bins.
  • --min-count is the fewest values a family is fitted to.
  • --tolerance is how far a fitted mean and standard deviation may be from the data's, as a share of the data's.
  • --drop-invalid leaves out values that are not numbers or lie outside the bounds, instead of stopping.
  • --out writes the best fit as YAML that a blueprint includes, and --plot draws the data against it as a PNG.
1
2
# Three families, a histogram of 8 bins, and the best fit written for the blueprint
desflow fit fitting/packing_times.csv --column packing_seconds --unit s --lower 0 --upper 10 --candidates triangular,gamma,empirical --bins 8 --min-count 30 --tolerance 0.2 --drop-invalid --out fitting/yaml/packing_fit.yaml --plot packing_fit.png

1
2
3
4
5
6
7
8
40 rows: 40 used, 0 missing, 0 invalid
family            status              AIC  KS stat KS p (approx.)  parameters or reason
triangular *      fitted            56.68   0.1258          0.511  low=0.546332, mode=1.2, high=2.83766
gamma             fitted            56.79   0.1157         0.6165  shape=9.55777, scale=0.15694 (can draw above the upper bound 10)
empirical         fitted                                           edges: 9 numbers, counts: 8 numbers
* best: triangular
Wrote fitting/yaml/packing_fit.yaml
Wrote packing_fit.png

The empirical row is now a histogram of 8 bins, and the gamma row is marked because a gamma can draw above 10 seconds. fitting/yaml/packing_fit.yaml is the file the fitting example's blueprint includes, so fitting/yaml/fitting.yaml now draws its packing times from this triangular.

Convert Parameters

A gamma takes a shape and a scale, not a mean and a standard deviation. desflow dist converts the measured times' mean of 1.5 seconds and standard deviation of 0.4832 seconds into them:

1
desflow dist gamma --mean 1.5 --std 0.4832

1
2
3
4
5
6
parameters: shape 9.63671, scale 0.155655
mean 1.5, std 0.4832
variability: low (std / mean 0.322)
with no random generator, every draw is 1.5
YAML: {dist: gamma, shape: 9.63671, scale: 0.155655}
Python: dist="gamma", shape=9.63671, scale=0.155655

The shape and scale are close to the gamma that desflow fit found from the 40 values. The last two lines are the service in a blueprint and in the builder.

Given a family's own parameters, desflow dist converts the other way. Each of these lines prints the family's mean and standard deviation, as in the output above, for each kind of parameter: a rate, a constant's value, a low and a high, and a shape and a scale:

1
2
3
4
desflow dist exponential --rate 0.4
desflow dist constant --value 4
desflow dist uniform --low 0.7 --high 2.7
desflow dist gamma --shape 9.63671 --scale 0.155655

The shop's arrivals, rate: 0.4, are 2.5 seconds apart on average. A triangular also takes a mode, its most likely value. The one desflow fit found has a mean of 1.53 seconds, close to the measured 1.5:

1
desflow dist triangular --low 0.55 --mode 1.2 --high 2.84

1
2
3
4
5
6
parameters: low 0.55, mode 1.2, high 2.84
mean 1.53, std 0.481785
variability: low (std / mean 0.315)
with no random generator, every draw is 1.53
YAML: {dist: triangular, low: 0.55, mode: 1.2, high: 2.84}
Python: dist="triangular", low=0.55, mode=1.2, high=2.84

desflow dist alone prints a table of every family with its parameters and a one-line summary, and Choosing Inputs explains the variability line:

1
desflow dist

Set Up an Editor

desflow schema prints the JSON Schema of a blueprint, for the release you installed. An editor that reads it offers the keys as you type and marks a misspelt one:

1
desflow schema > blueprint.schema.json

Set Up Your Editor names the file in the editor's settings.

Stability and Limits

  • Exit statuses. A command exits with status 0 when it succeeds. desflow run and desflow explain exit with status 1 for a file that does not load, and print each error with its file and line. desflow experiment exits with status 1 when a check fails, after writing every file, and with status 2 when the experiment is invalid. desflow fit exits with status 1 when no family is usable. desflow dist exits with status 1 for a family with no formula from a mean and a standard deviation, such as weibull. A usage error exits with status 2: a missing file or folder, an option value that is not valid such as --until abc, an unknown dist family or a parameter that breaks its rule, and a desflow fit column with a value that is not a number, unless --drop-invalid drops it.
  • Files, not Python objects. desflow run reads a blueprint. desflow explain also reads a builder Python file that defines a SimulationContext at module level. desflow experiment reads an experiment file, and desflow fit a CSV file. A builder or low-level script runs with Python, and replicate and run_experiment run its replications and experiments, as Replications shows.
  • JSON output. The shape of desflow explain --json is experimental through 1.x, and its schema_version changes when the shape does.
  • Examples need the network. desflow examples get downloads from GitHub, at the tag of the installed release. --ref names another tag or branch.
